Branded industrial grade LCD panels with perfect image quality and wide viewing angles;
Powered by reliable processor and other industrial-grade components for a 24/7 long time trouble-free operation;
Stable Android OS, supporting Ethernet / WiFi / Bluetooth / 4G network;
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration for extreme operation environment;
Stable quality, high reliability and long lifetime even in harsh conditions;
Ultimate solution for industrial embedded computing with customization
Model Name | AMG-21PPC01T7 |
CPU | RK3288 Quad core ARM-A17 CPU 1.8GHz |
RAM | 2GB(4GB optional) |
EMMC | 8GB(16/24/32GB optional) |
COM ports | 4 x COM ports |
HDMI port | 1x HDMI port |
USB Ports | 4 x USB ports |
OS | Android 5.1 |
Ethernet | WiFi , Ethernet,4G, Bluetooth |
Audio | Mic-in, Line-out |
SD Card | Support |
Screen Size | 21.5" |
Active Area(mm) | 476.064(H)x267.786(V) |
Pixel Pitch(mm) | 0.24795(H)x0.24795(V) |
Display Resolution | 1920x1080 |
Contrast Ratio | 3000:1 |
Brightness(cd/㎡) | 250nits |
Backlight | LED |
Viewing Angles | 178(H);178(V) |
Response Time | 18ms |
Touch Screen | IR Touchscreen |
Light Sensor | Optional |
Dimension(VxHxT)mm | 556.6x211.6x57.5 |
Operating Temperature | 0～50℃(non-condensation) |
Storage Temperature | -20～60℃(non-condensation) |
Relative Humidity | 5[%RH]～90[%RH] |
