Top LCD panel with a perfect image quality and high contrast ratio, industrial components to support 24/7/365 continuously operation;
Solid mechanical design to make sure normal work even under harsh environments
IP65 waterproof side frame integrated with capacitive touch screen, easy installation and maintenance, dust proof, vandal proof;
Popular multi points projective capacitive touch screen technology;
Options for high brightness and different video input interface;
Customized solution available to meet all kind information terminals
Model Name | AMG-21OPGX01T1 |
Screen Size | 21.5” |
Active Display Area(mm) | 476.064(H)x267.786(V) |
Pixel Pitch(mm) | 0.24795(H)x0.24795(V) |
Display Resolution (pixel) | 1920x1080 |
Contrast Ratio | 3000:1 |
Display Mode | Normally black |
Touch screen(optional) | PCAP Touch(10 points) |
Brightness (cd/㎡) | 250nits |
Backlight | LED |
Viewing Angles (CR=10) | 178(H)x178(V) |
Response Time(Typ.Tr+Tf) | 18ms |
Dimension(VxHxT) | 518.2x309.7x44.5 |
Signal Connector | VGA/DVI-D/HDMI/Audio |
Touch Interface | USB |
Input Voltage | DC12V |
Operating Systems Support | Windows 7/8/10 / Linux(optional) |
Operating Temperature | 0～50℃(non-condensation) |
Storage Temperature | -20～60℃(non-condensation) |
Relative Humidity | 5(%RH)～90(%RH) |
