Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Touchscreen is optional such as PCAP, Resistive etc., available for various sizes including our 8.4 inch industrial displays;
Robust mechanical design with Aluminum for metal IP65/NEMA 4 front panel to meet tough environmental conditions and requirements;
Easy-to-install with rack mounting enclosures.
Customization service available;
|
Model Name |
AMG-08IPZY03T1 |
|
Screen Size |
8.4" |
|
Active Display Area (mm) |
170.4(H)x127.8(V) |
|
Pixel Pitch (mm) |
0.213(H)x0.213(V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
800X600 |
|
Contrast Ratio |
600:1 |
|
Display Color |
262K |
|
Brightness (CD/㎡) |
1000 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
150(H)x150(V) |
|
Response Time(Typ.Tr+Tf) |
35ms |
|
Signal Connector |
VGA/DVI/USB |
|
Power Consumption |
DC2.0 |
|
Dimension(VxHxT) |
255X178X31.5 |
|
Operating Temperature |
-30~85℃ |
|
Storage Temperature |
-30~85℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
