This 21.5-inch standard-brightness LCD module has rich interfaces and strong anti-interference capability.
Key features
·Strong anti-interference capability
·1.5G vibration resistance
·Supports VGA, DVI input interfaces
·Customization solution available
Typical applications
·ATM machines
·Smart safes
·Indoor advertising screens
·Unmanned vending cabinets
Strong anti-interference capability
1.5G vibration resistance
Supports VGA, DVI input interfaces
Supports embedded, VESA and snap-in mounting
Integrated sleek appearance
Available as standard equipment solution
ATM machines
Smart safes
Indoor advertising screens
Unmanned vending cabinets
Branded LCD panels with perfect image quality and wide viewing angles
Built with industrial-grade components for a reliable 24/7/365 operation
LED backlight for low power consumption to save more energy
Various touchscreen options like PCAP, Resistive, IR, SAW etc
High-end mechanical design to meet tough environmental conditions and requirements
Customization solution available
Model Name | AMG-21OPHA01N1 |
Screen Size | 21.5" |
Active Display Area (mm) | 476.64(H) x 268.11(V) |
Pixel Pitch (mm) | 0.294(H) x 0.294 (V) |
Display Mode | Normally White |
Display Resolution (pixel) | 1920x1080 |
Contrast Ratio | 1000:1 |
Display Color | 16.7M |
Brightness (CD/㎡) | 250 |
Backlight | LED |
Viewing Angles (CR =10) | 178(H);178(V) |
Response Time(Typ.Tr+Tf) | 5ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 498x294.6x28 |
Operating Temperature | 0～50℃ |
Storage Temperature | -20～60℃ |
Relative Humidity | 5(%RH)～90(%RH) |
Touch Screen | Optional |
