This 12.1-inch Industrial Wall-mount PCAP Touch LCD Monitor.
Key features
·PCAP Touchscreen
·Plastic frame, rugged steel housing
·High reliability testing
·High brightness
·Light sensor optional
Typical applications
·Non-cash equipment
·VTM
·ATM
·Kiosk etc
| Specification | |
| Screen Size | 12.1" |
| Active Display Area(mm) | 245.76(H) x 184.32(V) |
| Pixel Pitch(mm) | 0.24(H)x0.24(V) |
| Display Mode | Normally white |
| Display Resolution(pixel) | 1024x768 |
| Contrast Ratio | 700:1 |
| Display Color | 16.2M |
| Brightness | 500nits |
| Backlight | LED |
| Viewing Angles(CR=10) | 160(H)X160(V) |
| Response Time(Typ.Tr+Tf) | 35ms |
| Touch Screen | PCAP |
| Signal Connector | VGA/DVI |
| Power Input | DC 12V |
| Touch Controller | USB |
| Operating Temperature | -30～80℃(not clotted) |
| Storage Temperature | -30～80℃(not clotted) |
| Relative Humidity | 5(%RH)～90(%RH) |
