13.3 Inch Android All-In-One Panel PC

The 13.3 inch industrial all in one computer AMG-13PPC01T2 customized by Amongo is widely installed in different applications with the following features:

  • High quality LCD panels with perfect image effect and wide view angles;

  • Latest Android OS, supporting Ethernet / Wi-Fi / Bluetooth / 4G network;

  • Full flat surface design to support front IP65 waterproof, dust proof and vandal proof with tempered glass;

  • Stable quality, high reliability to ensure the long time operation during bad environment;

  • Suitable solutions for all the projects related with AI and IoT ;


Contact Us
Products
Products

Key features

·PCAP multi-touchscreen

·Convex full flat fillet design

·IP65 waterproof, dust-proof, vandal-proof

·Supprot 4G/WiFi/ GPS /Ethernet

·Android 7.1 OS



Typical applications

·In-Vehicle Navigation & Entertainment

·IoT Smart Gateway / Control Hub

·Industrial HMI / Interactive Terminal

·Digital Signage & Multimedia Display

·Vandal-proof Public Self-service Kiosk



Specifications

Screen Size13.3"
Active Display Area(mm)293.76(H)x165.24(V)
Pixel Pitch(mm)0.153(H)x0.153(V)
Display ModeNormally Black
Display Resolution(pixel)1920x1080
Contrast Ratio600:1
Display ColorNormally Black
Brightness220nits
BacklightLED
Viewing Angles(CR=10)160(H);160(V)
Response Time(Typ.Tr+Tf)30ms
Touch ScreenPCAP Touch(10 points)
Operating Temperature0~50℃(non-condensation)
Storage Temperature-20~60℃(non-condensation)
Relative Humidity5(%RH)~90(%RH)
CPURK3399 Dual Cortex A72+Quad core A53 64bit CPU
RAM2GB(4GB Optional)
EMMC16GB( 8 / 32 / 64GB Optional)
OSAndroid 7.1
USB ports2 x USB 3.0
LAN4G/3G, 2 x Ethernet, WiFi, GPS Support
SD CardSupport
LED ports2 x LED
Speaker port1 x Speaker
Tel port1 x Telephone
