AMG-15IPNC01N2 is a display module that can reliably start and operate continuously in a wide range of high and low temperature environments. It is equipped with the commonly used DC24V power supply input and can adapt to extreme temperature differences in various industries such as indoor high-temperature enclosed spaces, extremely cold outdoor conditions, cold chain, and vehicle-mounted applications.
Key features
Industrial standard DC24V power input
Wide temperature range: -30℃ to 85℃
Fast response time: 8ms
Suitable for 7×24-hour operation
Brightness: 300～1000 nits (optional)
Signal Interface: DP (optional)
Operating Temperature: -30～85°C (optional)
Capacitive Touch Screen (optional)
Mounting & installation
Snap-in installation, side-hung installation
Typical applications
Internal operation terminal of the cold storage
Outdoor vending machine display screen
Power distribution room monitoring screen
Heat treatment workshop monitoring terminal
| Technical Specification | |
| LCD | |
| Model Name | AMG-15IPNC01N2 |
| Screen Size | 15" |
| Active Display Area(mm) | 304.128(H)x228.096(V) |
| Pixel Pitch(mm) | 0.297(H)x0.297(V) |
| Display Mode | Normally White |
| Display Resolution(pixel) | 1024x768 |
| Contrast Ratio | 700:1 |
| Display Color | 16.2M |
| Brightness | 350nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 160(H);140(V) |
| Response Time（Typ.Tr+Tf） | 8ms |
| Optional | |
| Touch Screen | PCAP Touch(10 points) |
| Light Sensor | Support |
| Tempered glass | Support |
| I/O Interface | |
| Signal Connector | VGA/DVI |
| Power Input | DC 24V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 363*280*76.5 |
| Environmental | |
| Operating Temperature | -30~85℃（non-condensation） |
| Storage Temperature | -30~85°C（non-condesation） |
| Relative Humidity | 5~90(% RH) |
