Aluminum front frame design
Support IP67 waterproof, dustproof
Strong industrial structure design
Application:
Kiosk/Industrial automation etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-22IPPC01T4 |
| Screen Size | 21.5" |
| Active Display Area(mm) | 473.76(H)x296.1(V) |
| Pixel Pitch(mm) | 0.282(H)x0.282(V) |
| Display Mode | Normally White |
| Display Resolution(pixel) | 1680x1050 |
| Contrast Ratio | 1000:1 |
| Display Color | 16.7M |
| Brightness | 300nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 178(H);178(V) |
| Response Time（Typ.Tr+Tf） | 8ms |
| Optional | |
| Touch Screen | PCAP Touch(10 points) |
| Light Sensor | Support |
| Tempered glass | Optional |
| I/O Interface | |
| Signal Connector | VGA/DVI |
| Power Input | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 573.7*400.1*66.9 |
| Environmental | |
| Operating Temperature | -0~50℃（non-condensation） |
| Storage Temperature | -20~60°C（non-condesation） |
| Relative Humidity | 5~90(% RH) |
