Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Durable mechanical design to meet tough environmental conditions and requirements;
Full flat surface design, for easy installation and maintenance
Customization service available
Model Name | AMG-21OPGD01T4 |
Screen Size | 21.5" |
Active Display Area (mm) | 476.64(H)x268.116(V) |
Pixel Pitch (mm) | 0.24825(H)x0.24825(V) |
Display Mode | Normally Black |
Display Resolution (pixel) | 1920x1080 |
Contrast Ratio | 3000:1 |
Display Color | 16.7M |
Brightness (CD/㎡) | 250nits |
Backlight | LED |
Viewing Angles (CR =10) | 178(H);178(V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA/DVI-D/HDMI/Audio |
Power Consumption | DC 12V |
Dimension(VxHxT) | 511.9x303.4x43 |
Operating Temperature | 0~50℃ |
Storage Temperature | -20~60℃ |
Relative Humidity | 5(%RH)~90(%RH) |
Touch Screen | PCAP Touch(10 points) |
