AMG-06OPHA01T1 is a compact liquid crystal display module featuring multiple interfaces and strong anti-interference performance. Thanks to its easy installation and stable operation, it is widely applied in various projects and fields including ATMs, smart safes, parking toll systems, etc.
Key features
Excellent wide temperature performance: -20℃ to +70℃
Vibration resistance: 1.5G
CCFL backlight design for easy replacement and low cost
Infrared touch screen with superior environmental adaptability
Equipped with multiple input interfaces, compatible with video output of various host devices
Mounting & installation
Base plate mounting & snap-in installation, integrated sleek appearance, standard matching solution for equipment
Typical applications
ATM
Smart safe
Parking toll terminal
Branded LCD panels with perfect image quality and wide viewing angles
Built with industrial-grade components for a reliable 24/7/365 operation
LED backlight for low power consumption to save more energy
Various touchscreen options like PCAP, Resistive, IR, SAW etc
High-end mechanical design to meet tough environmental conditions and requirements,
Customization service is available
Model Name | AMG-06OPHA01T1 |
Screen Size | 6.5" |
Active Display Area (mm) | 132.48 (H) x 99.36 (V) |
Pixel Pitch (mm) | 0.207(H) x 0.207 (V) |
Display Mode | Normally white |
Display Resolution (pixel) | 640x480 |
Contrast Ratio | 600:1 |
Display Color | 16.2M/262K colors |
Brightness (CD/㎡) | 500 |
Backlight | LED |
Viewing Angles (CR =10) | 140 (H); 120 (V) |
Response Time(Typ.Tr+Tf) | 25ms |
Signal Connector | VGA/DVI |
Power Consumption | DC 12V |
Dimension(VxHxT) | 156x130x37.4 |
Operating Temperature | -20～70℃ |
Storage Temperature | -20～80℃ |
Relative Humidity | 5(%RH)～90(%RH) |
