Model Name |
AMG-06IPPR01T1 |
|
Screen Size |
6.5" |
|
Active Display Area(mm) |
132.48(H)x99.36(V) |
|
Pixel Pitch(mm) |
0.207(H)x0.207(V) |
|
Display Mode |
Normally White |
|
Display Resolution(pixel) |
640x480 |
|
Contrast Ratio |
16.2M/262K |
|
Display Color |
600:1 |
|
Brightness |
800nits |
|
Backlight |
LED |
|
Viewing Angles(CR=10) |
160(H);140(V) |
|
Response Time(Typ.Tr+Tf) |
25ms |
|
Touch Screen |
Resistive touch(5 wire) |
|
Light Sensor |
Optional |
|
Tempered glass |
Optional |
|
Dimension(VxHxT) |
199.5x170x36.2 |
|
Signal Connector |
HDMI/DP |
|
Power Input |
DC 12V |
|
Touch Controller |
USB |
|
Operating Systems Support |
Windows 7/8/10 / Linux(optional) |
|
Operating Temperature |
-30~80℃(non-condensation) |
|
Storage Temperature |
-30~80℃(non-condensation) |
|
Relative Humidity |
5~90(%RH) |
