Branded 7-inch LCD industrial display monitor panels with perfect image quality and wide viewing angles, industrial-grade components for a reliable 24/7/365 operation;
Wide range of touchscreen technologies, including PCAP, Resistive, IR, etc., ideal for 7-inch monitor display screen applications;
High-end mechanical design to meet tough environmental conditions and requirements.
IP rating compliance to withstand water, dust, and dirt intrusion; anti-shock, anti-vibration;
Customization service available;
|
Model Name |
AMG-07IPPC01T1 |
|
Screen Size |
7" |
|
Active Display Area (mm) |
152.4 (H) x91.44 (V) |
|
Pixel Pitch (mm) |
0.1905 (H) x 0.1905 (V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
800x480 |
|
Contrast Ratio |
500:1 |
|
Display Color |
16.2M/262K colors |
|
Brightness (CD/㎡) |
350 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
110(H)x130 (V) |
|
Response Time(Typ.Tr+Tf) |
30ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
234.6x173.4x47.8 |
|
Operating Temperature |
-20~70℃ |
|
Storage Temperature |
-20~70℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
